| Standard Sizes |
| Standard: 8' x 20' thru 32' Optional: 8 1/2' x 20' thru 32' |
|
| GVWR | 16,000 | GAWR | (each |
| Coupler | 2-5/16" Ball Standard Adjustable Pipe | Safty Chains | 3/8" Transport w/ Grab Hook (2 ea.) |
| Jack | 10,000# Drop-leg Jack (Bolted on) | Neck | 10" Channel |
| Frame | 12' x 16# I-Beam | Crossmember | 3" I-Beam |
| Axle | Two 8000# Dexter Flanged w/ Electric Brakes | Suspension | Multi-leaf Slipper Spring w/ Equalizer |
| Tire | 215/75R17.5" Load Range H | Wheel | 6.00 x 17.5" - 8 Hole High Capacity |
| Floor | 2" Pine | Lights | D.O.T. Stop, Tail, Turn and Clearance |
| Electrical Plug | 6-Way | Finish Prep | Acid Etched w/ White Phosphorus, Undercoat w/ Panther 813 & Two Coats Primer |
| Finish | Painted w/ 2 Coats High Solid Supreme Acrylic Automotive Grade Enamel, and Pinstriped | Side Rails | 3" x 5" x 1/4"Angle w/ Rub Rail and Stake Pockets on 24" Centers |
